Sub Mersible Column Pipe

We have on offer the PE pipes for lowering submersible pumps. Being free of joints, the installation is easy and fast. These pipes are made as per IS 4984 and the product details are as presented below.

HDPE COLUMN PIPE
We also offer PE pipes for lowering submersible pumps. As it is free of.any joints the installation is very easy and fast. These pipes are made as per IS 4984 and the product details are given below.

UPVC COLUMN PIPES FOR SUBMERSIBLE PUMPS
Our quality tests ensure that they withstand load comprising of pump, water and pipe weight with adequate factor of safety. Shock and jerks are easily handled during operation due to unique design of square threads.
UPVC column pipes are light weight, offer has leak proof joints and long life with economy and high tensile load capacity. Therefore they emerge as the best option for conventional metal pipes.

Pipe Size

• 1", 1¼", 1½", 2", 2½", 3" and 4"
• Pressure Ratings : Standard Duty, Light Duty, Medium Duty.
• Imported Notes : Pipes are available in 3 meter length with square threads fitted with rubber sealing ring at male threaded end.

Casing Pipes conforming to IS 12818:1992
These pipes are available in deep blue colour and as per BIS standard. One end of the pipe is male threaded where as other end is female threaded socket. Threads are either V or trapezoid type and protection caps are provided on the threads to protect the threads in transit. Shallow Well (C.S.) and Medium Well (C.M.) pipes are available. Shallow Well pipes are suitable for depths up to 80 meters and Medium Well pipes can be used up to 250 meters.

Casing Pipe Available In Two Type

• Shallow Well – C.S. Type (Suitable up to 80 meters depth).
• Medium Well – C.M. Type (Suitable up to 250 meter depth).

Pipe Sizes

• 40 mm (1-1/2”) to 250 mm (10”)
• Standard Length: 3 meter
• Colour: Standard Blue
